FT-114-77 Nickel Zinc Ferrite Toroidal Core - Type 77 Material

About This Product

Looking for quality ferrite cores for your electronics projects?

The FT-114-77 Nickel Zinc Ferrite Toroidal Core is a popular choice among hobbyists, makers, and professionals working with high-frequency applications and noise suppression.

This toroidal core features Type 77 material, known for its useful characteristics across a range of frequencies.

It offers high saturation flux density at higher temperatures and maintains relatively low core loss in the 1 KHz to 1 MHz range.

These properties make it well suited for power conversion applications, wideband transformers, and various resonant circuits.

The core is also effective for noise attenuation in the 0.5 MHz to 50 MHz frequency range, which is valuable when designing filters, chokes, or other components where reducing electromagnetic interference is important.

Dimensions: Inner Diameter (ID): 0.748 inches Outer Diameter (OD): 1.142 inches Height (HT): 0.295 inches Many electronics enthusiasts choose Type 77 material for low power, high inductance applications and wideband projects.

The toroidal shape helps contain the magnetic field and can reduce unwanted radiation compared to other core geometries.

Whether you're building inductors, transformers, common mode chokes, or working on RF projects, these nickel-zinc ferrite cores provide a solid foundation for your designs.

The material performs well in situations where temperature stability and consistent performance matter.

Nickel-Zinc Ferrite Toroidal Core Type 77 Material High saturation flux density at high temperature Low core loss in the 1 KHz to 1 MHz range Suited for power conversion and wideband transformers Widely used for noise attenuation in the 0.5 MHz to 50 MHz range Good for low power, high inductance resonant circuits and wideband applications A versatile and commonly used ferrite core that continues to be a reliable option for many different electronic applications and DIY projects.
